SG9663TD Full HD 1080p Drive Recorder (optional 2 channel)
The SG9663TD is a WiFi enabled drive recorder. FULL HD 1080P DashCam Video Security Car DVR Appliance. Super-Capacitor + Metal Lens Holder-Base means Extreme Temperature Resistance!
- Novatek 96663 Processor, Sony IMX327 Exmor R CMOS Sensor, 7 element (6 glass + IR cut filter), IR cut, 127° lens resulting in a Crystal Clear Perfectly Focused Sharp Image!
- Full HD 1080P at 30fps @ up to 21Mbit/sec, H.264 Encoding MP4 format, GPS enabled.
- Large pixel native 1080P sensor + WDR means GOOD Night performance. MicroSD Card, USB/OTG Android Card Reader & GPS Logger SGGPSWM Included! Support for microSD cards up to 512GB!
- Optional Rear channel camera – sold separately.
- 2.7 inch HD TFT screen. Plunger mount for easy Install.
- Street Guardian Dashcam Viewer Mobile App compatible – FREE download on the Apple App store or Google Play Store.
- 1 Year No Hassle Warranty. Registration required to extend warranty to 2 years.
*Note: Hard wiring this camera requires an SGTDHW Wiring kit, sold separately.
Specifications:
- Processor: Novatek NT96663
- Lens: 7 Element, Metal chassis, Glass lens, IR cut, 127° viewing angle
- CMOS sensor: Sony Exmor R IMX327
- Video resolution: Full HD 1080P at 30fps @ selectable 15/18/21Mbit/sec – both front & rear camera.
- Video format: H.264 compression, MP4 format
- LCD display: 2.7 inch HD TFT screen
- Microphone: Built-in, on/off menu selectable
- Speaker: Built in
- Storage media: MicroSD card, Minimum 32GB Class10 recommended, 512GB maximum*
- Gapless recording: Supported
- Recording cycle: Menu selectable – 1 min/2min/3 min/5 min
- Date stamped video: Supported
- User selectable speed display: Supported
- Custom user text: Supported
- Soft shutdown: Supported, last file save and soft shutdown
- Screen saver: Supported, menu selectable – 5 min, 3 min, 1 min, 30sec, 15sec, 5sec
- Night mode: Wide dynamic range (WDR)
- Built-in G-sensor: Yes, with adjustable sensitivity
- Incident file protect: Automatic by G-Sensor/Manual emergency by one touch button
- GPS: Included (external)
- Exposure compensation: Menu selectable -2.0 to 2.0
- White balance: Auto
- WiFi: Yes
- Language: English/Spanish/Russian/Portuguese/German/Italian/Japanese/French/Simplified Chinese/Traditional Chinese
- Power supply: Fail-safe Super Capacitor
- RTC (Real Time Clock): Supported
- Dimensions Front (LxWxH): 80 x 32 x 48mm (excluding the bracket)
- Unit Net Weight Front: 66g
*Memory cards must be formatted in camera
User Manual SG9665TD – user manual English
[kc_row use_container=”yes” _id=”926705″][kc_column width=”12/12″ video_mute=”no” _id=”330857″][kc_title text=”U3RyZWV0IEd1YXJkaWFuIERhc2hjYW0gVmlld2VyIE1vYmlsZSBBcHA=” _id=”900017″ type=”h1″][/kc_column][/kc_row][kc_row use_container=”yes” _id=”348314″][kc_column width=”12/12″ video_mute=”no” _id=”914467″][kc_column_text _id=”379165″]
Download the Street Guardian Dashcam Viewer Mobile App. Available on the Apple App Store and Google Play store.
